Steel Formwork Props & Alumimium Formwork Props

Formwork props are height-adjustable steel or aluminium prop jacks that support formwork systems in slab and wall formwork construction. They are modular scaffolding materials with pre-designed components of holed inner tubes with top plates, outer tubes with prop sleeves and bottom plates, prop nuts, and prop lock pins (G Pin or straight pins).

Steel Formwork Props



Steel shoring prop, also known as steel adjustable prop, is generally welded from Q235 and S45 steel tubes. It is heavier with strong rigidity and solid structure, so it can reach high load classes and resist deformation well. It is suitable for high-load construction and long-term site projects. Available with painted or hot-dip galvanized surface treatment, the steel adjustable prop can be reused for multiple cycles.

Alumimium Formwork Props



Aluminium shoring prop, or aluminium adjustable prop, is made of aluminium alloy profiles. It weighs much less than steel formwork prop, allowing easier handling and faster assembly by workers on site to save labour cost and construction time. It mainly serves medium and light load applications with good toughness, ideal for regular slab and residential building projects. The aluminium alloy material will not rust, bringing lower long-term operating costs and delivering better performance in coastal areas.

Slab and Wall Formwork Props

Props are adjustable shoring parts of the formwork system. They support formwork panels, formwork beams (like H20 timber beams and aluminium beams), and plywood in concrete slabs, beams, and walls. Compared to shoring scaffolding in formwork, the props are telescopic and standard independent, which is more efficient and easier for formwork construction.

Construction formwork props, known as shuttering props, include slab single props, push-pull single and double brace props, and trench props according to the design and function.

Slab single props are the most popular construction props for concrete formwork. They are used to support concrete slabs and beams vertically in construction.

Push-pull props brace the formwork panels in the wall and column formwork concrete. Push pulls can be single-braced or double-braced.

Slab Formwork Props

Push-pull props

Formwork Prop Types

Formwork props are essential accessories for concrete construction. We supply three popular types of formwork props for different regional construction requirements:

✅ Acrow Props

✅ Shoring Props

✅ Post Shores

Acrow props are adjustable steel vertical supports for formwork and scaffolding.

They have a 48mm OD inner tube and a 60mm OD outer tube. The sleeve comes with cast steel or forged prop nuts, and G-shaped or straight lock pins to fix the height.

Acrow props are strong for high loads and reusable on site. They are also known as acro supports, acro jacks, acrow jacks and acro props.

They serve as temporary supports for structures, concrete slabs and beams during construction.



Acrow Props

Shoring props are light-duty telescopic steel props for construction.

They have two common tube sizes: 40mm inner tube with 48mm outer tube, or 48mm inner tube with 56mm outer tube. They come with handled prop cup assembly, sleeve nut, inner and outer tubes, top & bottom plates and G pin.

Also known as Spain props or Italian props, these props can be painted or galvanized for corrosion protection.

They are easy to operate and cost lower. Designed for light load civil construction to support concrete slabs, they can be reused many times.



Shoring Props

Post shores are heavy-duty steel props with larger tubes and high load capacity to bear heavy pressure.

They are popular in the USA and Canada for concrete formwork of thick slabs and beams in commercial, industrial and plant construction.

They are also called shore post, pole shore, post shore jack and post shore prop.

OEM service is available.



Post Shores

Why Us

Wellfit supply full ranges of formwork props including acrow props, shoring props and post shores. Our acrow props, also called acro jacks and acro supports, shoring props known as Spain props and Italian props, post shores named shore post, pole shore and post shore jack, both can be customised.

We can customize the adjustable height, inner & outer tube dimensions, top plate and bottom plate sizes for your acrow formwork props. Light-duty, medium-duty and heavy-duty formwork props are available to match your load requirements and project budget.

Our formwork props are fully compatible with most concrete formwork systems and leading formwork brands, including Soffit Formworks, Ulma, Doka, Peri and other shuttering systems.

Whether you need acrow props, shoring props or post shores for concrete slab and beam formwork, you can get high-quality formwork props with competitive factory price from us. OEM service is available for all types of formwork shoring props.

Contact us to get your formwork prop solution and load test report for your construction project.

Get The Latest Price Now

As one of the most professional formwork shoring props manufacturers and suppliers in China, we have world-leading production equipment and strong manufacturing capabilities. Please feel free to buy high quality formwork shoring props at competitive price from our factory.
