Rapid Clamp Tensioner

Rapid Clamp Tensioner
Details:
Rapid formwork clamp tensioner is the most efficient and reliable tool for anchoring and locking formwork during concrete casting. The system guarantees fast set-up and ultra-fast removal for formwork, making it extremely popular in the construction industry. The rod is gripped strongly by the wedge, made of hard steel, with longitudinal grooves that grip the iron rod to prevent it from slipping.  Formwork Clamps prevent structural failure in formwork and ensure perfectly straight castings.  As a leading manufacturer of CE-certified formwork clamps, we offer high-quality concrete formwork clamps. Importing clamps from Wellfit at the factory price saves on purchasing costs. Tell us your formwork clamp requirements to get a good price now!
Send Inquiry
Description
Send Inquiry

Products Specification

Product Name

Formwork Rapid Clamp Tensioner

Material

Ductile Cast Iron

Weight

1.4kg

Surface

Galvanized

A rapid clamp tensioner is a tool used to tighten and loosen formwork rapid clamps to make tie bars straight and tight in concrete. It is one of the formwork accessories most commonly used in formwork, concrete, and shuttering. More than the rapid clamp tensioner, it has other names like spring clamp tensioner, wedge clamp tensioner, etc.

-7







How to use it?

1. Choose a tie bar in required length

2. Put the tie bar inside the rapid clamp hole (tie bar diameter 6-10mm)

3. Insert tie bars into a set of formwork panels (tie bar one end with rapid clamp at one end)

4. Put a tube between formwork panels and ensure formwork panels are correct

5. Go through the tie bar to the other side of the formwork panels

6. Use rapid clamp tensioners connect with formwork rapid clamp

7. Lock formwork rapid clamp by the gear of rapid clamp tensioner

8. Screw the rapid clamp tensioner jacks make the tie bars tighten and straight

9. Unlock gears and remove the tensioner

-8



Application

Woodworking

Securely holds materials for cutting, gluing, or assembly

Metalworking

Provides firm grip for welding and fabrication tasks.

General Maintenance

Ideal for repair tasks requiring high tension

Industrial Use

Ensures stability in heavy-duty applications





Why choose us?

Wellfit Scafform is a leading formwork and scaffolding manufacturer in China. Customized formwork and scaffolding are acceptable upon drawing or sample. In the past 15 years of manufacturing, Wellfit scaffoldings and formworks have been exported to more than 50 countries.

Wellfit has its own test labs. Complete test facilities are used to control scaffold and formwork quality. You can find raw material test reports, welding penetration, galvanizing and painting adherence test reports, load capacity reports, etc. All of the tests are conform to standards of BS1139, EN39, EN74, EN 12810, BS2482, AS1576, etc.



Main products: various formwork systems, ringlock scaffolding,cuplock, kwikstage, quick lock, twist lock, scaffolding frames, tubes & couplers, scaffold boards, etc
