Specification
| Product Name | Formwork anchor nut |
| Process | forged |
| Types | Three-wing nuts |
| Diameter |
12mm,14mm,15mm,16mm,17mm,20mm (Compatible with the diameter of the tie rod) |
| Finish | Zinc-coated or colorful zinc-coated |
| Material | High-strength steel |
| Packing | Ton bag, pallets, and wooden crates upon your requirements |
| Application | Wall formwork/ Slab formwork/Column formwork/Beam formwork/Table formwork/ Climbing formwork/Tunnel formwork etc |
How to choose a suitable size of formwork anchor nut for tie rods?
D12 Tie Rod Choose D12 anchor Nut
D14 Tie Rod Choose the D14 anchor Nut
D15 Tie Rod Choose the D15 anchor Nut
D16 Tie Rod Choose the D16 anchor Nut
D17 Tie Rod Choose the D17 anchor Nut
D20 Tie Rod Choose the D20 anchor Nut
How to choose forged anchor nuts and cast anchor nuts?
Forged anchor nuts
Forged anchor nuts are made under high temperature,after hammering, processing to deform the metal into the anchor nut shape. With high tensile strength, good yield strength and toughness,no risk of cracking or deformation. It is widely adopted by famous brands, such as Tekko formwork, Doka formwork, Meva formwork, etc. Forging has higher mold and processing costs, suitable for mass production of high-standard nuts.
Cast anchor nuts
Cast anchor nuts are used widely in light load, static load, and low-stress occasions. Casting has a lower production cost and a simple process, fit for low-demand and ordinary low-strength fasteners.
How to Use
1. Align the Tie Rod: Insert the tie rod through the formwork panels.
2. Attach the Wing Nut: Place the formwork wing nut to the exposed end of the tie rod.
3. Tighten by Hand: Using the winged edges, tighten the nut securely to hold the formwork panels in place. No additional tools are needed.
4. Ensure Stability: Confirm that the panels are tightly secured, preventing any movement during the concrete pouring process.
Why choose us?
Wellfit Scafform is a leading formwork and scaffolding manufacturer in China. Customized formwork and scaffolding are acceptable upon drawing or sample. In the past 15 years of manufacturing, Wellfit scaffoldings and formworks have been exported to more than 50 countries.
Wellfit has own test labs. Complete test facilities are used to control scaffold and formwork quality. You can find raw material test reports, welding penetration, galvanizing and painting adhere test report, load capacity report etc. All of the tests are conformed to standards of BS1139, EN39, EN74, EN 12810, BS2482, AS1576 etc.
Main products: various formwork systems, ringlock scaffolding,cuplock, kwikstage, quick lock, twist lock, scaffolding frames, tubes&coupler, scaffold boards etc.
